Ampule Sealer (S type)
click to enlarge each pictures		It is easy to seal by setting up the Ampule on the holder, transferring it to Sealer position and picking up its tip with tweezers. Revolution of Ampule is done by roller, so it seals evenly, and it can be done well even for the first time user with limited experience. It is unnecessary to lay a pipe for the air since small sized compressor is already built in. Specs Targeted Ampule: 1mL ~ 20mL Sealing capacity: more than 100bottles / hr Sealing Gas: City gas or LPG Power Supply: 100V Machine Size: W172 x D208 x H240mm
click to enlarge each pictures

Automatic Ampule Sealer (A type)
		This machine seals automatically by supplying the filled Ampule to StarWheel. It can be used for 1mL ~ 20mL of Ampule by changing the position of StarWheel or exchanging it. It is suitable for the research center of production for small amount. Specs Targeted Ampule: 1mL ~ 20mL Capacity: more than 400bottles / hr Sealing Gas: City gas or LPG + enzyme Compressed Air: 0.2Mpa Power Supply: AC100V 1A Machine Size: W230 x D410 x H390mm Weight: 14kg

Automatic Ampule Sealer (NF-1 type)
		This is the sealing machine that automatically substitutes nitrogen gas to filled ampule. With exchanging the StarWeel, it can be workable for 1mL ~ 20mL of Ampule, and because it is light weighted and small size, it can be operated in Clean Bench. Specs Targeted Ampule: 1mL ~ 20mL Capacity: more than 400bottles / hr Sealing Gas: City gas or LPG + enzyme Compressed Air: 0.2Mpa Power Supply: AC100V 0.7A Machine Size: W270 x D420 x H400mm Weight: 19kg

Automatic Ampule filling / Sealing Machine (OAS-1 type)
		This machine allows to fill chemical into Ampule and Seal it automatically. Operation is simple and there are little exchange parts. It is also light weighted and very compact. It is excellent for the use at the hospital and research center. Specs Targeted Ampule: 1mL ~ 20mL Capacity: more than 400bottles / hr Sealing Gas: City gas or LPG + enzyme Compressed Air: 0.2Mpa Power Supply: AC100V 0.7A Machine Size: W285 x D410 x H400mm Weight: 19kg

Ampule Filling / Sealing Machine (NF-2 type)
		This machine can do nitrogen replacement, filling liquid and sealing by supplying the cleaned Ampule on StarWheel. For the use of 1mL to 10mL, it doesn't require parts exchange but only changing the position is necessary. And installing the Conveyer (opiton), the Ampule can be supplied without waste. Specs Targeted Ampule: 1mL ~ 20mL Capacity: more than 400bottles / hr Replacement of Nitrogen Gas: Before replacement Sealing Gas: City gas or LPG + enzyme Compressed Air: 0.2Mpa Power Supply: AC100V 20W Machine Size: W285 x D475 x H465mm Weight: Approx. 25kg


Ampule Filling / Sealing Machine (NF-3 type)
		This is small machine that operates filling, Sealing and replacement of Nitrogen automatically. As it adopts before and after replacement, it can produce the reliable pharmaceutical. SUS316 is used. It also uses Glass / Silicon Tube. Because it is light weighted and small size, it can be operated in Clean Bench, and recommended most for the use at hospital and research center. Specs Targeted Ampule: 1mL ~ 20mL Sealing Capacity: more than 400bottles / hr Replacement of Nitrogen Gas: Before and after replacement Sealing Gas: City gas or LPG + enzyme Compressed Air: 0.2Mpa Power Supply: AC100V 25W Machine Size: W400 x D590 x H490mm Weight: Approx. 26kg
